Sectional unit
SPS

Product description

Standard versions of the SPS suspended sectional air handling units can be specially adapted to the individual needs and preferences of the customer.

download product sheet
Output
300 do 5,400 m³/h
Device type
Suspended
Automation system
Plug&Play
*option
Filter types
(ISO)
Coarse (G4)
ePM10 (M5)
ePM1 (F7)
ePM1 (F9)
Casing frame
construction/self-supporting construction
Installation
Indoor
Application
Warehouses, offices, workshops, industrial halls

Product features

Type SPS suspended HVAC is a full air handling unit for ventilation and air conditioning of industrial rooms, warehouse rooms, wholesale operations rooms, workshops, and office spaces. They comprise a wide selection of components for handling and delivery of air within project-specific performance limits. The HVAC units are manufactured as monoblock units, resulting in compact sizes, a critical feature for installation beneath suspended ceiling systems. The configuration of components and integrated automatic controls of the HVAC unit ensure indoor comfort is maintained in all rooms.

  • filter classes: G4, M5, F7, F9, H11
  • self-supporting structure
  • removable covers (easy access)
  • wide range of parameter configurations
  • compact dimensions
  • quiet operation (insulation up to 70mm)
  • High-quality thermal and acoustic properties
  • possibility to set the unit on legs
  • full automation
  • Plug&Play system (full internal wiring)

Construction

The design of the SPS suspended HVAC units is based on a self-supporting shell. The unit’s enclosure is formed by type C shell panels and removable panels. The panels of the HVAC unit are made of aluzinc outer metal sheets and galvanised inner sheets forming the cladding for a mineral wool core. The mineral wool core has good thermal insulating and sound attenuating performance. The standard mineral wool core thickness is 50 mm. 70 mm is optional and available on order.

The HVAC units are provided with flexible duct connectors which isolate the vibration transmitted by the ductwork on site. The suspended HVAC units can be installed on support feet, in which case service access is only provided from the top.

Good thermal and acoustic properties

(50/70mm insulation)

Flexible nozzles isolating the air handling unit

from vibrations transmitted by ducts

Wide range of configuration and selection of components

to individual customer requirements

Variants

Choose your unit

Unit size Dimensions Air output
[mm] [m3/h]
width (B) height (H) min. max.
MINI 500 435 300 1100
SPS-1 780 435 900 2500
SPS-2 1090 435 1400 3900
SPS-3 780 535 1200 3350
SPS-4 1090 535 2000 5400

Automation
and Plug&Play (optional)

For manufactured air-handling units, VBW Engineering delivers complete automation systems. VBW Engineering can also install, commission, and service the HVAC units with the aid of highly qualified and experienced service personnel. The HVAC unit control solutions are always adapted to the specific project requirements for the building and its users’ individual needs.

The idea of the PLUG & PLAY automation system is to prepare the control system of the air handling unit so that it is ready for immediate operation.
VBW Engineering offers air handling units together with a factory-fitted automation system. Internal wiring and switchgear with the controller mounted on the air handling unit.

&PLUGPLAY
&PLUGPLAY

Advantages of using
the PLUG & PLAY system

Reduced installation and commissioning time
(cost reduction)
Commissioning without disturbances
caused by difficult atmospheric conditions
Electrical connections made and checked by
qualified technicians
Certified
electrical terminations, certified cable junction boxes and connections
Would you like to find out more?
Contact our representative contact
